Home Elevators

Residential elevators and through-floor home lifts for private residences, from hoistway elevators to self-supporting lifts that travel through a floor opening.

10 planning guides

Compare the models

Planning figures from each home elevator guide. Open a guide for the full detail, the conditions behind each number and its sources.

Home Elevators: planning figures by model
Model	Rated load	Max travel	Stops	Pit	Power
Spire Home ElevatorHarmar	500 lb	164 3/4 in; 15 ft 9 in option	2	No pit	115 V, 20 A breaker
AnteraCibes Symmetry	770 lb	Up to 49.2 ft	Up to 6	0 to 3 15/16 in	208/230 VAC, 30 A
AscendaCibes Symmetry	770 lb	Up to 14 ft	2	No pit	230 V, 30 A
LumaSavaria	400 lb	Up to 165 1/4 in	2	No pit	110 to 240 VAC, 5 A
Connect Compact, Connect Classic, Connect XL (ELV-3600)Bruno	500 lb	Up to 161 in; 189 in special order	Not published	Not published	110 V, 60 Hz
TelecabSavaria	500 lb	Up to 23 ft	2	No pit	110 VAC, 20 A
VueliftSavaria	500 to 950 lb	Up to 50 ft	Up to 6	3 to 12 in	230 V, 30 A
Duo AltaStiltz	375 lb	Up to 14 ft 9 3/16 in	2	No pit	220 to 240 V, 10 to 20 A
EclipseSavaria	750 to 1000 lb	Up to 50 ft	Up to 6	8 to 10 in	230 V, 1-phase, 30 A
Trio AltaStiltz	550 lb	Up to 19 ft 8 1/4 in	Up to 3	No pit	220 to 240 V, 10 to 20 A

Scroll the table sideways to see every column.

Home Elevators planning guides

Harmar
Spire Home Elevator
Plan a Harmar Spire Home Elevator (formerly Pollock): three cabin sizes, floor opening, ceiling heights, 115 V power, NJ and PA code path and checklists.
Cibes Symmetry
Antera
Plan a Cibes Antera home elevator, with a Cibes shaft or cab only: 770 lb load, pit, overhead, power, unpublished dimensions, and NJ and PA codes.
Cibes Symmetry
Ascenda
Plan a Cibes Ascenda shaftless home elevator: four sizes, hatch cut-outs, 0 in pit, 92 in overhead, two dedicated circuits, trade roles and NJ and PA codes.
Savaria
Luma
Plan a Savaria Luma through-floor lift: floor opening, ceiling heights, rail loads, battery power, NJ and PA code path, trade roles and checklists.
Bruno
Connect Compact, Connect Classic, Connect XL (ELV-3600)
Plan a Bruno Connect home elevator (Compact, Classic, XL): cab sizes, 500 lb load, travel, dedicated 110 V supply, site data to request, NJ and PA codes.
Savaria
Telecab
Plan a Savaria Telecab through-floor lift: 500 lb, 23 ft travel, cab sizes, floor cut-out, support wall, 96 in overhead, power and NJ and PA codes.
Savaria
Vuelift
Plan a Savaria Vuelift glass or acrylic home elevator, Vuelift Mini included: footprints, pit, overhead, floor loads, 230 V power and NJ and PA codes.
Stiltz
Duo Alta
Plan a Stiltz Duo Alta through-floor homelift: floor cut-out, 93 in ceiling, 220 to 240 V power, NJ and PA code path, trade roles and checklists.
Savaria
Eclipse
Plan a Savaria Eclipse or Eclipse HD home elevator: hoistway sizes, 8 in pit, 96 in overhead, 230 V power, landing doors, NJ and PA codes, trade checklists.
Stiltz
Trio Alta
Planning guide to the Stiltz Trio Alta and Trio Alta Thru-Car: floor opening, ceiling height, load, power, the NJ and PA code path, trade roles and checklists.
